Frac Sand Dryer
Professional frac sand dryer manufacturer for silica sand and proppant sand processing. Customized drying solutions with high output and low maintenance cost.
Features:
- Capacity: 3-120 T/H (Customizable)
- Moisture Reduction: 25% → 3%
- Heat Source: Coal / Gas / Biomass
- Powdery materials: (1)Construction sands: river sand, sea sand, yellow sand, quartz sand, foundry sandplate sand, steel sand, fracturing sand; (2)Mineral & mining materials: tailings sand, copper ore sand, iron ore sand, coloredsand, fluorite powder, potash feldspar powder, sodium feldspar powder. (3)And other building materials sands and industrial bulk materials. Process: Drying → Dust Collection → Screening.
Frac Sand Dryer Machine
Efficient Drying Solution For Oilfield Frac Sand And Industrial Silica Sand Processing
Working Principle
(1) Wet sand is fed from the raw material bin into the rotary drum dryer via a feeder and conveyor. Under a gas-fired heat source, the material is continuously dispersed and lifted, achieving efficient heat exchange and rapid moisture removal.
(2) The exhaust gas containing dust is drawn into a cyclone and dust collection system for purification, with dust available for recycling.
(3) The dried material is then conveyed to a vibrating screen for classification into different particle sizes according to production requirements. The entire system is automatically controlled to regulate temperature and moisture, ensuring stable operation and a final moisture content of 0.5%–1%.
Our Advantages:
Refund available if yield falls below standard
30% Energy Saving
Three-Pass Drying Structure
Anti-Blocking Design
Uniform Sand Drying
Low Maintenance
5-Year Warranty
CE Certified
Customized Capacity
Applicable Materials
Facturing Sand
Glass Sand
Iron Powder
Quartz Sand
Titanium Powder
Machine-made Sand
Slag
Stone Powder
River Sand
Specifications
| Model | Power（KW） | Capacity(T/H) | Rotary speed （r/min） | Installation Angle | final Moisture | Heat Supply Mode |
| HG1625 | 4kw | 3-8 t/h | 9 | Aclinic | ≤0.5％ | 1) Firewood 2) Pulverized coal 3) Diesel 4) Natural gas 5) not carbonizedbiomass fuel 6) carbonizedbiomass fuel |
| HG2240 | 7.5kw | 10-15 t/h | 9 | |||
| HG2250 | 7.5kw | 20t/h | 9 | |||
| HG2958 | 5.5kw*4 | 30t/h | 7 | |||
| HG3270 | 11kw*4 | 60t/h | 7 | |||
| HG3890 | 15kw*4 | 100t/h | 7 |
